Java MySQL JSON Display Records using Jquery.
Wall Script
Wall Script
Monday, August 27, 2012

Java MySQL JSON Display Records using Jquery.

This is the continuation of my previous Java tutorial Insert Records into MySQL database using Jquery, now I want to explain how to convert records data into JSON data format and display JSON data feed using Jquery. It's simple just follow few steps with Eclipse IDE, hope you understand the Model View Controller pattern Thanks!

Java JSON Jquery Display Records

Download War File    Download Project Source

Database
Sample database messages table contains two columns msg_id and message.
CREATE TABLE `messages`
(
`msg_id` int(11) NOT NULL AUTO_INCREMENT,
`message` text,
PRIMARY KEY (`msg_id`)
)

Previous Tutorial: Java MySQL Insert Record using Jquery.

Step 1
Create a new package called dto (Data Transaction Objects).

Right click on src -> New and then select Package.
Java JSON Jquery Display Records

Give Package name and click finish.
Java JSON Jquery Display Records

Step 2
Now you have to create a Class, right click on dto -> New - Class
Java JSON Jquery Display Records

MessageObjects.java
Here you have declare all transaction objects, in this tutorial transaction objects are msg_id and message
package dto;

public class MessageObjects
{
//Message Objects
private String msg_id;
private String message;
//Getters and Setters
}

Step 3
You have to generate Getters and Setters, just right click on the code.
Java JSON Jquery Display Records

Goto Source and select Generate Getters and Setters
Java JSON Jquery Display Records

The follow popup window will appear, now select all transaction objects and click Ok.
Java JSON Jquery Display Records

Automatically Eclipse will generate so code. This system very useful, if sometimes we have large number of transaction objects.
Java JSON Jquery Display Records

Step 4
For JSON data format you have to copy gson.jar into library folder. Download code contains these JAR files.
Java JSON Jquery Display Records

Step 5
Data Access Object(dao) Package
Java JSON Jquery Display Records

Project.java
Create a method GetMessages with Arraylist datatype, using select statement getting results from messages table. Binding results into messageData object.
package dao;
import java.sql.Connection;
import java.sql.PreparedStatement;
import java.sql.ResultSet;
import java.util.ArrayList;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import dto.MessageObjects;
public class Project
{
public String InsertMessage(Connection connection, HttpServletRequest request,
HttpServletResponse response) throws Exception {
// Previous Post
}

public ArrayList GetMessages(Connection connection,HttpServletRequest request,HttpServletResponse response) throws Exception
{
ArrayList messageData = new ArrayList();
try
{
PreparedStatement ps = connection.prepareStatement("SELECT msg_id,message FROM messages ORDER BY msg_id DESC");
ResultSet rs = ps.executeQuery();
while(rs.next())
{
MessageObjects messageObject = new MessageObjects();
messageObject.setMsg_id(rs.getString("msg_id"));
messageObject.setMessage(rs.getString("message"));
messageData.add(messageObject);
}
return messageData;
}
catch(Exception e)
{
throw e;
}
}

}

Step 6
Model class model package

ProjectManager.java
Here you have to write the business logic eg: User session validation
package model;

import java.sql.Connection;
import java.util.ArrayList;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import dao.Project;
import dto.MessageObjects;

public class ProjectManager {
public String InsertMessage(Connection connection, HttpServletRequest request,
HttpServletResponse response) throws Exception {
//Previous Post
}

public ArrayList GetMessages(Connection connection, HttpServletRequest request,
HttpServletResponse response) throws Exception {
ArrayList messages = null;
try {
// Here you can validate before connecting DAO class, eg. User session condition
Project project= new Project();
messages=project.GetMessages(connection, request, response);

catch (Exception e) {
throw e;
}
return messages;
}

}

Step 7
Create servlet class in controls package.
Java JSON Jquery Display Records

GetMessages.java
Converting messageData object data to JSON data format. Add servlet class mapping in web.xml file inside WEB-INF directory.
package controls;

import java.io.IOException;
import java.io.PrintWriter;
import java.sql.Connection;
import java.util.ArrayList;
import javax.servlet.ServletException;
import javax.servlet.annotation.WebServlet;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import com.google.gson.Gson;

import dao.Database;
import model.ProjectManager;
import dto.MessageObjects;

@WebServlet("/GetMessages")
public class GetMessages extends HttpServlet {
private static final long serialVersionUID = 1L;

public GetMessages() {
super();
}

protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
response.setContentType("text/html;charset=UTF-8");
PrintWriter out = response.getWriter();
try
{
Database database= new Database();
ProjectManager projectManager= new ProjectManager();
ArrayList messagesData = null;
Connection connection = database.Get_Connection();
messagesData = projectManager.GetMessages(connection, request, response);
Gson gson = new Gson();
String messages = gson.toJson(messagesData);
out.println("{\"Messages\":"+messages+"}");
}
catch (Exception ex)
{
out.println("Error: " + ex.getMessage());
}
finally
{
out.close();
}
}
}

JSON Output for messages data.
{
"Messages":[
{
"msg_id":"3",
"message":"Everything is possible. "
},
{
"msg_id":"2",
"message":"9lessons Programming Blog http://9lessons.info"
},
{
"msg_id":"1",
"message":"Make People fall in love with Your Ideas"
}
]
}

Step 8
Final step display JSON data using Jquery.

index.jsp
Using $.ajax calling GetMessages servlet then reading JSON data with $.each method and appending data into content div.
<script type="text/javascript" src='js/jquery.min.js'></script>
<script type='text/javascript'>
$(document).ready(function()
{
$.ajax
({
type: "GET",
url: "GetMessages",
dataType:"json",
success: function(data)
{
if(data.Messages.length)
{
$.each(data.Messages, function(i,data)
{
var msg_data="<div id='msg"+data.msg_id+"'>"+data.message+"</div>";
$(msg_data).appendTo("#content");
});
}
else
{
$("#content").html("No Results");
}
}
});
$('#UpdateButton').click(function()
{
// Previous Post
});
return false;
});
});
</script>
//HTML Code
<textarea id='Message'></textarea><br/>
<input type='button' value=' Update ' id='UpdateButton'/>
<div id='content'></div>

Step 9
You can dowload the WAR file and import into your Eclipse IDE. Run this project at http://localhost:8080/SecondProject/index.jsp
